Synthesis and characterization of 3D printed hybrid photochromic materials
DOI:
https://doi.org/10.33448/rsd-v14i8.49280Keywords:
Hybrid, PMMA, Tungsten Oxide, 3D Printing.Abstract
This research aimed to produce transparent and photochromic polymer-WO3 hybrid parts by FDM 3D printing (layer-by-layer Fused Deposition Modelling) for optical applications. A laboratory investigation was conducted employing the polyol method for the synthesis of sub-stoichiometric tungsten oxide WO3-x, which was subsequently subjected oxidized by potassium dichromate K2Cr2O7. The photochromism of the synthesized WO3 was confirmed after irradiation under UV lamp. Experiments with several polymers showed that PMMA is the most suitable polymer for composing the matrix of the hybrid material. PMMA-WO3 hybrid blocks were produced by a solution route and characterized by UV-vis-NIR spectrophotometry, showing its photochromism. As the required diameter of filaments for 3D printing is 1.75 mm, fibering has been found ineffective for the production of PMMA-WO3 adequate hybrid filaments. Extrusion was chosen as the method for obtaining filaments for 3D printing, but due to technical problems with the extruder, the diameters of the filaments obtained were not close enough to 1.75 mm to be printed directly by FDM.
References
Agrawal, A., Johns, R. W., Milliron, D. J. (2017). Control of Localized Surface Plasmon Resonances in Metal Oxide Nanocrystals. Annual Review of Materials Research, 47(1), 1–31.
Andron, I (2020). Oxydes et fluorures photochromiques inorganiques : approches expérimentale et calculatoire. Université de Bordeaux.
Badour, Y., Danto, S., Albakour, S., Mornet, S., Penin, N., Hirsch, L., Gaudon, M. (2023). Low-cost WO3 nanoparticles/PVA smart photochromic glass windows for sustainable building energy savings. Solar Energy Materials and Solar Cells, 255, 112291 (11 p.).
Badour, Y. (2023). Unlocking the Potential of Photochromic Tungsten Oxide (WO3-x) Materials : Synthesis, Characterization, and Shaping of Hybrid Organic-Inorganic WO3-Doped Systems (0D, 1D, 2D) for Optical Applications. Université de Bordeaux.
Bensebaa, F. (2013). Chapter 2 - Wet Production Methods. Interface Science and Technology, Nanoparticle Technologies. Editora Elsevier, 19, 85–146.
Bourdin, M. (2020). Poudres et films à base d’oxyde de tungstène WO3 pour applications photoniques : photochromisme et électrochromisme. Université de Bordeaux, Université Laval.
Brayner, R., Fiévet, F., Coradin, T. (2013). Nanomaterials: A Danger or a Promise?: A Chemical and Biological Perspective. Editora Springer-Verlag. Atlas.
Dong, H., Chen, Y. C., Feldmann, C. (2015). Polyol synthesis of nanoparticles: status and options regarding metals, oxides, chalcogenides, and non-metal elements. Green Chem, 17(8), 4107–4132.
Fraser, R. A., Stoeffler, K., Ashrafi, B., Zhang, Y., Simard, B. (2012). Large-Scale Production of PMMA/SWCNT Composites Based on SWCNT Modified with PMMA. ACS Appl. Mater. Interfaces, 4(4), 1990–1997.
Gil, A. C. (2017). Como elaborar projetos de pesquisa. (6 ed.). Editora Atlas.
Hajduk, B., Bednarski, P., Jarka, H., Janeczek, M., Godzierz & T. Tański. (2021). Thermal and Optical Properties of PMMA Films Reinforced with Nb2O5 Nanoparticles. Scientific Reports, 1(1), 22531.
Hui, B., Wu, D., Huang, Q., Cai, L., Li, G., Li, J., Zhao, G. (2015). Photoresponsive and Wetting Performances of Sheet-like Nanostructures of Tungsten Trioxide Thin Films Grown on Wood Surfaces. RSC Adv., 5(90), 73566–73574.
Le Duigou, A., Chabaud, G., Castro, M. (2021). Impression 3D/4D de matériaux composites thermoplastiques. Techniques de l’ingénieur. https://www.techniques-ingenieur.fr/base-documentaire/materiaux-th11/finitions-des-plastiques-fabrication-additive-des-polymeres-42475210/impression-3d-4d-de-materiaux-composites-thermoplastiques-bm7922/
Li, Y., Peng, S., Miao, J., Zheng, L., Zhong, J., Wu, L., Weng, Z. (2020). Isotropic Stereolithography Resin Toughened by Core-Shell Particles. Chemical Engineering Journal, 394, 124873.
Pardo, R., Zayat, M., Levy, D. (2011). Photochromic Organic–Inorganic Hybrid Materials. Chem. Soc. Rev, 40(2), 672–687. https://doi.org/10.1039/C0CS00065E.
Pereira, A. S. et al. (2018). Metodologia da pesquisa científica. [free ebook]. Editora UFSM.
Piard, J. (2013). Le photochromisme : définition et applications. Le Bulletin de l'Union des Professeurs de Physique et de Chimie, 107(954), pp.549-559. Le Bulletin de l'Union des Professeurs de Physique et de Chimie, 107 (954), pp.549-559.
Pierre, C. (1999). L’analyse calorimétrique différentielle (DSC) : application à la chimie. L’Actualité Chimique, N°222, 13. Société Chimique de France (SCF).
Strutynski, C. (2015). Fibres tellurites pour sources supercontinuum infrarouges : gestion des profils opto-géométriques et des absorptions extrinsèques, Université de Bourgogne.
Valette, S. (2024). Techniques de caractérisation des céramiques. Techniques de l’ingénieur. https://www.techniques-ingenieur.fr/base-documentaire/materiaux-th11/ceramiquesproprietes-et-elaboration-42578210/techniques-de-caracterisation-des-ceramiques-n4806/.
Zheng, H., Zhen Ou, J., Strano, M. S., Kaner, R. B., Mitchell, A., Kalantar-zadeh, K. (2011). Nanostructured Tungsten Oxide – Properties, Synthesis, and Applications. Advanced Functional Materials, 21(12), 2175–2196.
Zidan, H. M.; Abdelrazek, E. M. (2005). Structural and Optical Properties of PMMA Films Filled with Different Contents of Iodine. International Journal of Polymeric Materials, 54(11), 1073–1085.
